A "Cross-Field" tape recorder with AB test, "Sound-on-Sound", "Add-a-track", echo, mono and stereo mixing.
Year of manufacture: 1972
Transistor configuration: 38 transistors, 17 IC
Number of heads: 4 (erase head, recording, playback, pre-magnetization)
Speaker: none
Inputs: Mic, radio, line
Output power (AF power): Radio: 0.75V into 5kohm.
Line: 1.5V into 200 ohm.
Frequency response (DIN 45511): 40Hz to 25kHz
Number of motors: 1 hysteresis synchronous motor and 2 reel motors.
Tape speed: 1 7/8, 3 3/4, 7 1/2
Reel diameter: 7"
Cabinet: teak, rosewood or oak
Accessories: Electrical remote control for start, stop, fast forward, record and playback (RC-9), case and dust cover.
|
Model |
Tracks |
Price NOK |
Dimensions cm |
Weight kg |
Notes |
|
Model 9021 X |
2 |
40x41x18 |
15.5 |
|
Instrument lighting and power: 24v 50mA
End stop: 14v with leads
