A cassette recorder with Actilinear Recording and Dolby noise reduction, AB-test, 3 motors, MPX filter (for FM stereo recording), headphone jack on the front and manual azimuth adjustment.
Year built: 1979
Transistor configuration:
Number of heads: 3
Speaker: none
Inputs: Mic, radio and line.
Output power: Radio: 0.775V into 5 kohm.
Line: 1.5V into 100 ohm.
Headset: 1.5V into 8 ohm.
Frequency response (DIN 45500): 20Hz to 20kHz
Number of motors: 1 hysteresis servomotor and 2 reel motors.
Tape speed: 1 7/8
Reel diameter: cassette
Cabinet: Black aluminum front with black side panels.
Accessories: Wireless remote control (RC20T and RC20R)
Model Tracks Dimensions cm Weight kg Notes
TCD 440 stereo 4 46.5x22.5x10 6.7
Fuses: 2AT, 315mAT 5x20mm
