A cassette tape recorder with Dolby B noise reduction, AB-test, 3 motors, MPX filter (for FM stereo recording), headphone jack on the front, and manual azimuth adjustment of the tape.
Year of construction (year):
Transistor configuration (trans.):
Number of heads (heads): 3
Speaker (speaker): none
Inputs (input): Mic, line and radio
Output power (output): Radio: 0.775V into 5 kohm.
Line: 1.5V into 100 ohm.
Headset: 5mW into 8 ohm
Frequency response (DIN 45500): 20Hz to 20kHz
Number of motors (motors): 1 hysteresis synchronous motor and 2 reel motors.
Tape speed (speed): 1 7/8
Reel diameter (wheel dia.): cassette
Cabinet (cabinet): Aluminum front with black side panels.
|
Model |
Tracks |
Dimensions cm |
Weight kg |
|
TCD 330 stereo |
4 |
47x23x10,5 |
6,6 |
1st version uses counter belt 300001
Fuse 2AT 5x20
